Cheap JINHANIC JDS2012A Digital Handheld Oscilloscope 1 Channels 20MHz 200MSa/s Sample Rate Os (EU Plug)

Cheap JINHANIC JDS2012A Digital Handheld Oscilloscope 1 Channels 20MHz 200MSa/s Sample Rate Os (EU Plug)

Cheap JINHANIC JDS2012A Digital Handheld Oscilloscope 1 Channels 20MHz 200MSa/s Sample Rate Os (EU Plug)

Product ID : 32890710397
Price : $114.64
Discount Price : $96.30

VISIT WEBSITE NOW

Item specifics
  • Display Size:
    3.0 – 4.9 Inches
  • Band Width:
    Less than 60MHz
  • Max Waveform Capture Rate:
    30,000wfm/s
  • Digital Channels:
    1
  • Display resolution:
    640*480 Pixels
  • IS Battery Demountable:
    Yes
  • Model Number:
    Digital Handheld Oscilloscope 1 Channels
  • Record Length:
    4K
  • DIY Supplies:
    Electrical
  • Real Time Sampling Rate:
    200MSa/s
  • N:
    Digital Handheld Oscilloscope 1 Channels
Product Description
LNHF

JINHANIC JDS2012A Digital Handheld Oscilloscope 1 Channels 20MHz 200MSa/s Sample Rate Os (EU Plug)

It is an electronic tool used to graphically depict sound waves and environmental frequencies.
This tool is helpful in a number of different applications. Some of the most common include music, particularly radio frequencies and digital music remastering, but it can also be helpful in certain circuitry and engineering scenarios and in doing things like measuring seismic activity and certain other sounds in nature
Digital multimeter.
Plug Type: EU Plug, it applies to Indonesia, Germany, France, Spain, Italy and so on.
200MSa/s sample rate and 20MHz bandwidth. color TFT LCD, 320 x 240 pixels.
You could switch menu language between English and Chinese.
Powered by 1 x 18650 Li-ion battery.
Oscilloscope Function:
Input coupling: AC / DC
Input impedence: 1megohm 25pF
Maxium input voltage: 40V (probe 1X), 400V (probe 10X), 2000V (optional probe 100X)
Memory depth: 4K
Vertical sensitivity: 10mV – 5V (probe 1X), 100mV – 50V (probe 10X) (1, 2.5, 5 step)
Vertical accuracy: 3 percent
Vertical resolution: 8bit
Bandwidth: 20MHz
Real-time sampling rate: 200MSa/s
Horizontal scan range: 10nS/div – 5S/div
Trigger mode: auto, normal and single
Cursor measurements: support time and voltage cursors
Multimeter Function:
DC voltage: 400mV / 4.000V / 40.00V / 400.0V / 4000V
AC voltage: 400mV / 4.000V / 40.00V / 400.0V / 750V
Resistance: 400.0Ohm / 4.000kOhm / 40.00kOhm / 400.0kOhm/ 4.000MOhm/ 40.00MOhm
Capacitance: 51.20nF / 512.0nF / 5.120uF / 51.20uF / 100uF
Diodes: 0V – 1.5V
Continuity: less than 60ohm (buzzer)
Full count range: 4000
colour: gray
Material: PU
size: 21*10*3.5cm
Screen: 3.2 inch
Package Contents:
1*1:10 probe
1* multimeter pen
1*Disc
1* usb data cable
1* battery charging head
1* screen protection film
1*18650 5000MA battery
Only the above package content, other products a
It is an electronic tool used to graphically depict sound waves and environmental frequencies.
This tool is helpful in a number of different applications. Some of the most common include music, particularly radio frequencies and digital music remastering, but it can also be helpful in certain circuitry and engineering scenarios and in doing things like measuring seismic activity and certain other sounds in nature
Digital multimeter.
Plug Type: EU Plug, it applies to Indonesia, Germany, France, Spain, Italy and so on.
200MSa/s sample rate and 20MHz bandwidth. color TFT LCD, 320 x 240 pixels.

LNHF





Packaging Details
  • Unit Type:
    piece
  • Package Weight:
    0.907kg (2.00lb.)
  • Package Size:
    20cm x 10cm x 4cm (7.87in x 3.94in x 1.57in)
